Home > Products> Non Asbestos Gasket Sheet> High-Performance Non-Asbestos Latex Fiber Gasket Sheet – Heat Resistant, Oil Resistant, Ideal for Pumps, Engines, and Flanges

High-Performance Non-Asbestos Latex Fiber Gasket Sheet – Heat Resistant, Oil Resistant, Ideal for Pumps, Engines, and Flanges

Basic Information

Place of Origin:	CHINA
Brand Name:	CLINGSEAL
Certification:	ISO,SGS
Model Number:	NXB150

Minimum Order Quantity:	500KGS
Price:	1.5-4 USD PER KG
Packaging Details:	pallets or wooden case
Delivery Time:	10-20 days
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	200Tons per month

Get Best Price Contact Now

Detail Information

Color:	Black	Material:	Non Asbestos
Application:	Sealing Of Flanges, Pumps, Valves, And Other Industrial Equipment	Density:	1.5 G/cm3
Compressibility:	5-15%	Recovery:	35%
Working Temperature:	150Deg	Temperature Range:	-100°C To 400°C
Thickness:	0.5-6.0 Mm	Usual Color:	Green, Blue, Black, Red
Oil Resistance:	Good	Pressure Range:	Up To 100 Bar
Tensile Strength:	10-20 MPa	Water Resistance:	Good
Pressure:	2.0-5.0Mpa	Feature:	Wide Range Of Temperatures
Steam Resistance:	Good	Chemical Resistance:	Resistant To Most Chemicals Except Strong Oxidizing Agents
Temperature:	200-500 Celsius Degrees	Fluid Compatibility:	Wide Range Of Fluids
Length:	1000-1500 Mm	Elongation:	10%
Custom Sizes:	Available Upon Request	Certifications:	FDA, RoHS, REACH
Sealing Performance:	High	Size:	Standard Sizes Or Customized
Flexural Strength:	15 MPa	Standard Size:	1000mm X 1000mm

Product Description

High-Performance Non-Asbestos Latex Fiber Gasket Sheet – Heat Resistant, Oil Resistant, Ideal for Pumps, Engines, and Flanges 0

High-Performance Non-Asbestos Latex Fiber Gasket Sheet – Heat Resistant, Oil Resistant, Ideal for Pumps, Engines, and Flanges

If you're seeking a top-notch sealing solution, the high-performance non-asbestos latex fiber gasket sheet is a standout choice. It's available in thicknesses from 0.5mm to 5mm. A useful guideline: select the thinnest sheet that meets your application demands. This not only helps cut costs but also ensures the product delivers optimal performance.

Makeup and Manufacturing Steps

This high-performance gasket sheet is composed of aramid fiber, non-asbestos mineral fiber, synthetic fiber, and synthetic oil-resistant rubber. Its production involves hot-roller compression and vulcanization. These steps are crucial in creating a gasket with a strong internal structure, high density, and excellent physical properties.

Product Varieties

The product comes in different varieties, each with a specific peak temperature tolerance (denoted by numbers). This ensures there's a suitable option for various temperature conditions in different applications.

Key Traits

Non-Asbestos and Certified: Safety is paramount, and this gasket sheet is 100% asbestos-free, providing a secure working environment. It's also certified by ISO9001 UKAS, a testament to its high quality and adherence to strict manufacturing standards.

Superior Sealing: It forms a tight seal, effectively preventing the leakage of fluids and gases. Notably, it doesn't delaminate, which is vital for maintaining a consistent seal over time. The high production yield rate guarantees a quality product.

Heat and Oil Resistance: As highlighted in the title, it excels in heat resistance, making it suitable for high-temperature environments. Its excellent oil resistance also makes it perfect for applications where oil is present.

Durable and Adaptable: Built to last, this gasket sheet can withstand mechanical vibrations, pressure changes, and temperature fluctuations without losing its sealing ability. Its adaptability to different working conditions ensures a long service life, reducing the need for frequent replacements.

Economical: Whether used in pumps, engines, or flanges, it offers a cost-effective solution. You don't have to compromise on performance to save money.

Suitable Applications

Engines: In engines, it seals various components, preventing the leakage of oil, coolant, and exhaust gases. This helps the engine operate efficiently and reduces the risk of damage.

Pumps: It plays a key role in pumps by sealing crucial parts, preventing fluid leakage and ensuring efficient pump operation.

Flanges: When used on flanges, it creates a tight seal, stopping the leakage of fluids and gases. This is essential for the safe and efficient operation of flange connections.

Other Areas: Beyond pumps, engines, and flanges, it's also suitable for air compressors, gearboxes, and pipelines, contributing to their smooth and reliable operation.

Physical Property:

Items			CSNXB150	CSNXB250	CSNXB350
Tensile Strength		Mpa	7.0	8.0	10.0
Compressibility		%	7-17
Recovery		≥%	40	45	50
Creep relaxation		≤%	40	35	30
Density		g/cm3	1.8±0.1
Flexibility at room temperature		Bend 180°C on the rod with diameter which is 12 times of nominal thickness of the sample, no crack.
Immersed into ASTM 3# at 150ºC for 5h	Tensile Strength	MPa≥	5.0	6.0	7.0
Immersed into ASTM 3# at 150ºC for 5h	Weight Increase	≤%	30
Immersed into ASTM B at21-30ºC for 5h	Thickness Increase	-	0-20
Immersed into ASTM B at21-30ºC for 5h	Flexibility	-	No crack
Working Temperature	Max/Continuous	ºC	200/150	300/250	350/300
Working Pressure	Max/Continuous	MPa	2.0/1.0	4.0/2.0	5.0/3.0

Product Shows

Product Technical Details
As a general rule, Non-asbestos jointing gasket sheet is:
• Good for use with water
• Good for use with petrol
• Have good resistance to oil

High-Performance Non-Asbestos Latex Fiber Gasket Sheet – Heat Resistant, Oil Resistant, Ideal for Pumps, Engines, and Flanges 5

High-Performance Non-Asbestos Latex Fiber Gasket Sheet – Heat Resistant, Oil Resistant, Ideal for Pumps, Engines, and Flanges 6
