Detail Information

Grade:	Industrial Grade	Type:	Flexible Sheet
Application:	Oil & Gas, Chemical, Power	C Content (%):	99.9%
Thickness:	Tailored Dimensions/Shapes	Material:	Graphite,High Pure Graphite
CE Marking:	CE - Certified	RoHS Compliance:	Lead - Free/RoHS - Compliant
ISO Certification:	ISO 9001/14001
Highlight:	Sealing Graphite Sheet Material , Corrosive Resistant Graphite Sheet Material , Global Logistics Reinforced Graphite Sheet

Product Description

Products Description

Global Logistics Graphite Sealing Material

Graphite sealing materials include flexible sheets, foils, papers, tapes, and strips. These logistics-grade sealants are produced by chemically treating natural graphite flakes and subjecting them to high-temperature exfoliation, forming vermicular graphite structures with approximately 0.003g/cm³ density. The binder-free expanded graphite is calendared into rolls, offering:

99%+ purity for contamination-free logistics
Chemical resistance for corrosive environments
Extreme temperature stability (-200°C to +650°C) for global shipping conditions
Compression resilience for long-term sealing performance
Self-lubricating properties for easy installation
Gas-tightness for pressure-sensitive logistics applications

These features make our graphite sealing solutions ideal for international logistics equipment, including:

Key Applications in Global Logistics:

Container sealing systems
Pipeline gaskets for cross-border transportation
High-temperature insulation for logistics machinery
Valve packing rings in international shipping equipment

Logistics-Optimized Specifications:

Roll Widths: 1000mm / 1500mm (standard for global container dimensions)
Coil Lengths: 30m / 50m / 80m (economical for bulk logistics)
Sheet Sizes: 1000x1000mm / 1500x1500mm (intermodal compatible)
Thickness Range: 0.15-5.0mm (customizable for logistics equipment)
Density: 0.8-1.25g/cm³ (lightweight yet durable for international shipping)

Global Logistics Advantages:

Composite options with corrosion-resistant metal layers
Custom die-cutting for international equipment standards
ISO-certified packaging for safe global transportation
Quick turnaround for logistics industry emergencies

Item	Standard Value
C concentration	99%
S concentration	<1000ppm
chlorine concentration	<45ppm
tensile strength	4.5MPa
compressibility	>40%
recovery	>10%
Temperature	-200ºC-600ºC
Pressure	20MPa
Terence of Thickness	-0.04mm~+0.04mm
Terence of Dimension	In accordance with your Gasket size
Terence of Density	-0.06~g/cm3+0.06gcm3

Grades Separate :JB/T53392-1999

Mechanical Data		Qualified product	Top Grade	Superior Grade
Density Tolerance g/cm3	<0.4	±0.10	±0.05
	≥0.4	±0.07
Tensile Strength MPa		≥3.2	≥4.5	≥5.0
Compression Ratio %		35~55
Rebound Rate %		≥9	≥11	≥12
Stress relaxation rate %		≤10
Ash %		≤6.0	≤3.0	≤1.0
Heat loss on ignation %	450ºC	≤1.0		≤0.5
	600ºC	≤20		≤15
Sulphur content		≤1500ppm	≤1000ppm	≤600ppm
Chloride content		≤100ppm	≤50ppm	≤20ppm

Global Logistics Sealing Graphite Sheet Material Corrosive Resistant 0

Global Logistics Sealing Graphite Sheet Material Corrosive Resistant 1

Global Logistics Sealing Graphite Sheet Material Corrosive Resistant 2

Tag:

Place of Origin:	CHINA
Brand Name:	CLINGSEAL
Certification:	ISO,SGS
Model Number:	CSG80

Minimum Order Quantity:	500kg
Price:	2.2USD PER KG
Packaging Details:	pallet/wooden case
Delivery Time:	20 days
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	500Tons per month
