Product Specification
Place of Origin: China
Brand Name: clingseal
Certification: ISO,SGS
Model Number: CS2080T
Minimum Order Quantity: 500KGS
Price: USD 2.15-3.0 PER KG
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100Tons per month
Product Details
Highlight:

Graphite Double-Sided Metal Gasket

,

Heat Resistance Graphite Gasket Sheet
Magnetic Properties: Non-Magnetic Or Magnetic
Surface Finish: BA / NO.4 / 1D /2D / 2BB / 2BD
Certiificate: ISO
Standard Or Nonstandard: Standard
Standard: JIS, AISI, ASTM, GB, DIN, EN ,etc
Product: Stainless Steel Coil
Surface: 2B/BA/NO.1/NO.4/HL/8K
Cutting Method: Laser/Waterjet Cutting
Sample: Availble
Material: Graphite、metal
Application: Oil & Gas, Chemical, Power
Astm Standard: ASTM - Compliant
Temperature Range: -200℃ To 650℃
Iso Certification: ISO 9001/14001
Compressibility: ≥ 40%
Machinability: Ease Of Cutting/Shaping
Ce Marking: CE - Certified
Pressure Resistance: Up To 200 Bar
Tensile Strength: ≥ 4.0 MPa
Type: Gasket Sheet
Pressure Range: Up To 200 Bar
Product Description

CLINGSEAL Graphite Double - Sided Metal Gasket: Your Ideal Sealing Partner in Latin America

In Latin America's booming industries like automotive, energy, and manufacturing, harsh conditions demand top - tier sealing solutions. CLINGSEAL, a global sealing tech leader, presents the Graphite Double - Sided Metal Gasket, perfect for exhaust pipes, engine flanges, and turbo systems in Latin American markets.

1. Core Composition: The Foundation of Excellence

The gasket combines metal and graphite.
  • Metal Component: We use 0.2 - 0.25mm thick metal sheets. Standard is carbon steel (tinplate), and for better corrosion resistance, there are SS201, 304, 316 stainless steels.
  • Graphite Component: High - quality flexible graphite sheets with carbon contents of 95%, 97%, 98%, 99% are available, suiting diverse application needs.

2. Outstanding Features

2.1 Adaptability and Durability

It easily conforms to irregular flange surfaces, ensuring a reliable seal even with minor misalignments. This leads to a longer service life and less downtime, crucial for Latin American factories.

2.2 Superior Sealing

It has excellent sealing properties with no delamination, preventing leaks and equipment failure. Vital for exhaust pipes to meet emission standards in Latin America.

2.3 Economic Efficiency

Offers a balance between cost and performance, reducing sealing material costs without compromising quality, helping Latin American businesses allocate resources efficiently.

2.4 Resistance to Harsh Conditions

Withstands high temperatures, pressures, and exposure to oils/water, ensuring safe and efficient equipment operation.
Test Condition Performance Indicator Result
150°C, ASTM 3# Oil, 5 hours Weight Increase ≤30%
150°C, ASTM 3# Oil, 5 hours Thickness Increase ≤20%
21 - 30°C, ASTM B Fuel, 5 hours Weight Increase ≤30%
21 - 30°C, ASTM B Fuel, 5 hours Thickness Increase ≤20%

3. Tailored for Key Applications

3.1 Exhaust Pipe Sealing

Prevents exhaust gas leakage, improving engine efficiency and helping meet emission standards as automotive use rises in Latin America.

3.2 Engine Flange Sealing

Stops oil/coolant leaks and contaminant entry, ensuring smooth engine operation under heavy loads.

3.3 Turbo Sealing

Provides a secure seal for turbochargers, boosting engine performance, reducing fuel consumption, and lowering emissions.

4. Comprehensive Specifications

4.1 Thickness Options

Ranges from 1.0mm to 6.0mm. A 3 + 2 form (Metal - Paper - Metal - Paper - Metal) is available for higher - demand applications.
Thickness Range Typical Application
1.0 - 3.0mm General - purpose sealing (e.g., small engine flanges)
3.0 - 6.0mm Medium - pressure/temperature sealing (e.g., industrial exhaust pipes)
3 + 2 form (Thicker) High - pressure/temperature sealing (e.g., large turbo systems)

4.2 Size Options

Standard sizes: 500×500mm, 500×1000mm, 500×1500mm, 1000×1000mm, 1000×1500mm. Custom sizes are also offered.

5. Why Partner with CLINGSEAL?

  • Global Expertise, Local Support: A dedicated team familiar with Latin American industries provides technical assistance.
  • Reliable Quality: Rigorous testing ensures top standards, backed by warranties and after - sales support.
  • Innovation: Continuous R&D keeps us at the forefront of sealing tech, offering cutting - edge solutions.
Choose CLINGSEAL for superior performance, cost - effectiveness, and a trusted partnership in Latin America's sealing needs.
