Composite Non-Asbestos Gasket Plate with Graphite and Metal Reinforcement
Engineered for Diesel Engines, Repair Workshops, and Gasket Manufacturers Across South America and Brazil
Company Profile & Market Adaptability
At ClingSeal (Anqing ClingSeal Sealing Manufacturing Co., Ltd.), we produce high-quality non-asbestos gasket plates reinforced with steel and enriched with graphite for superior sealing performance. With two decades of factory experience and over eight years of active exports to Latin America, our company has built a reputation for providing reliable gasket materials to clients in Brazil, Argentina, Chile, Peru, Colombia, and other MERCOSUR countries.
Unlike conventional gasket sheets, the CS-Series composite plates are specifically designed to withstand the climatic, mechanical, and industrial challenges of South America — ranging from humid Amazonian conditions to high-load diesel engines in agricultural tractors, mining trucks, and marine fleets.
Why Latin American Gasket Factories Prefer ClingSeal
| Feature | Description | Benefit for Importers & Manufacturers |
|---|---|---|
| Direct Manufacturing Supply | Produced in our ISO9001-certified Chinese facility | Stable pricing & quality, long-term supply reliability |
| Graphite Enhancement | Improved thermal conductivity & lubrication | Better sealing for high-temperature diesel applications |
| Metal Reinforcement | 0.20–0.25 mm perforated carbon steel or stainless steel | Strength & durability in workshop cutting machines |
| Export-Proven | Over 8 years in Latin American markets | Packaging adapted to long-distance sea freight & customs needs |
| Customizable Dimensions | Wide sheet size options + tailor-made orders | Perfect fit for both industrial cutters and manual fabrication |
Technical Characteristics of CS-Series Composite Gasket Plates
| Parameter | Specification |
|---|---|
| Material Composition | Dual non-asbestos fiber layers + graphite blend + perforated steel core |
| Sheet Thickness (Single Layer) | 0.50 mm – 3.00 mm |
| Total Thickness Range | 1.00 mm – 6.00 mm |
| Available Sheet Sizes | 500×500 mm, 500×1000 mm, 500×1500 mm, 1000×1000 mm, 1000×1500 mm |
| Custom Dimensions | Acceptable upon request |
| Temperature Resistance | Up to 350°C |
| Oil Resistance | Excellent |
| Metal Options | Carbon steel, SS201, SS304, SS316 |
| Certification | ISO9001, SGS Tested, 100% Non-Asbestos |
Application Scenarios in South American Industries
-
Agricultural Engines: Cylinder head gaskets for tractors and harvesters in Brazil (Mato Grosso & Paraná).
-
Mining & Heavy Machinery: Sealing solutions for ore conveyors, generators, and industrial presses in Chile & Peru.
-
Marine Engines: Durable gasket plates for Atlantic fishing fleets and coastal transport vessels.
-
Local Workshops: Raw plate supply for São Paulo, Buenos Aires, and Bogotá gasket cutting plants.
Commercial Advantages for Latin American Importers
| Advantage | Value for Buyers |
|---|---|
| Regulatory Compliance | Meets Brazilian NR-15 & MERCOSUR asbestos-free standards |
| Profit-Oriented Pricing | FOB starting at USD 1.07/KG with 500 KG MOQ |
| Efficient Supply Chain | Production capacity of 100 tons/month with 10–20 day lead times |
| Bilingual Service | Technical assistance in Portuguese, Spanish, and English |
| Packaging Security | Moisture-proof plastic wrapping + reinforced wooden cases |
Order & Logistics Terms
| Item | Detail |
|---|---|
| MOQ | 500 KGS |
| FOB Pricing | From USD 1.07/KG |
| Payment Methods | T/T, Western Union, MoneyGram |
| Lead Time | 10–20 Days |
| Capacity | 100 Tons per Month |
| Export Ports | Shanghai, Ningbo |
| Shipping Options | Sea freight to Santos, Buenos Aires, Callao; air freight upon request |
After-Sales Services
-
On-site Installation Guidelines (Portuguese, Spanish, English)
-
Troubleshooting Assistance for specific diesel or marine applications
-
Product Evolution Updates for long-term distributors
-
Continuous Technical Support for OEM factories and local gasket manufacturers
FAQ
Q: What is the brand of this gasket plate?
A: ClingSeal
Q: What is the product model number?
A: CS1070T
Q: Where is it manufactured?
A: Produced in China, exported worldwide
Q: Which certifications are included?
A: ISO9001, SGS, asbestos-free guarantee
Q: What payment options are available?
A: T/T, Western Union, MoneyGram
-
