Laser-Cuttable Non-Asbestos Gasket Sheet
Custom Size Industrial Sealing Material for OEM Fabrication, Flanges, Pumps and Compressors
Product Overview
This laser-cuttable non-asbestos gasket sheet is developed for OEM fabrication, industrial maintenance, and project-based sourcing where precision cutting, flexible sizing, and supply chain efficiency are critical. The material is engineered to deliver clean laser cuts, consistent sealing performance, and stable physical properties across a wide range of industrial applications.
Designed for global export markets, the sheet supports custom dimensions, die-cut parts, and combined sourcing with other sealing materials, helping procurement teams simplify supplier management and logistics.
Thickness options range from 0.5 mm to 5.0 mm, enabling buyers to select the most efficient material thickness for cost control and performance optimization.
Material Structure & Manufacturing Process
| Item |
Description |
| Reinforcement |
Aramid fiber & synthetic mineral fibers |
| Binder System |
Oil-resistant NBR-based synthetic rubber |
| Manufacturing Method |
High-density compression molding with vulcanization |
| Asbestos Content |
0% (fully non-asbestos) |
| Process Compatibility |
Suitable for laser cutting, CNC cutting, and die cutting |
Key Advantages for OEM & Procurement Teams
This gasket sheet is specifically designed to meet the expectations of industrial buyers and sourcing managers:
-
Laser-Cut Friendly: Produces smooth edges with minimal charring or deformation
-
Custom Size Ready: Supplied in sheets, rolls, or precision-cut gaskets
-
Stable Batch Quality: Uniform density ensures repeatable sealing results
-
Multi-Media Resistance: Performs reliably with oils, fuels, water, gas, and steam
-
Supply Chain Efficiency: Supports one-stop sourcing and consolidated export shipments
Media Compatibility & Sealing Performance
| Contact Medium |
Performance Description |
| Industrial Oils |
Excellent resistance, minimal swelling |
| Water & Coolants |
Stable sealing, no material breakdown |
| Petrol & Fuels |
Maintains structure and sealing integrity |
| Natural Gas |
Reliable leakage prevention |
Temperature Grades & Typical Applications
Different grades are available to match operational temperature requirements.
| Grade |
Continuous Temperature |
Peak Temperature |
Typical Use |
| CSNXB150 |
Up to 150°C |
200°C |
Pumps, compressors, cooling systems |
| CSNXB250 |
Up to 250°C |
300°C |
Diesel engines, gearboxes, pipelines |
| CSNXB350 |
Up to 350°C |
400°C |
Exhaust systems, high-temperature flanges |
Common Industrial Applications
This laser-cuttable non-asbestos gasket sheet is widely used in:
-
OEM gasket fabrication
-
Pumps and air compressors
-
Internal combustion engines
-
Gearboxes and transmission housings
-
Pipe flanges and industrial pipelines
-
Marine and general industrial equipment
Its clean cutting behavior makes it ideal for workshops using laser cutters or CNC systems to produce custom gasket shapes on demand.
Sheet Sizes & Custom Fabrication Options
| Thickness Range |
Standard Sheet Sizes (mm) |
Custom Services |
| 0.5–5.0 mm |
1500×1500 |
Custom dimensions |
| |
1500×2000 |
Laser-cut parts |
| |
1500×4500 |
Die-cut gaskets |
| |
1270×1270 |
OEM drawings supported |
| |
1270×3810 |
Mixed-item export |
Physical & Mechanical Properties
| Property |
CSNXB150 |
CSNXB250 |
CSNXB350 |
| Tensile Strength (MPa) |
7.0 |
8.0 |
10.0 |
| Compressibility (%) |
7–17 |
7–17 |
7–17 |
| Recovery (%) ≥ |
40 |
45 |
50 |
| Creep Relaxation (%) ≤ |
40 |
35 |
30 |
| Density (g/cm³) |
1.8 ± 0.1 |
1.8 ± 0.1 |
1.8 ± 0.1 |
Working Limits
| Grade |
Max / Continuous Temp (°C) |
Max / Continuous Pressure (MPa) |
| CSNXB150 |
200 / 150 |
2.0 / 1.0 |
| CSNXB250 |
300 / 250 |
4.0 / 2.0 |
| CSNXB350 |
350 / 300 |
5.0 / 3.0 |
One-Stop Sourcing & Export Support
To support procurement efficiency, we offer:
-
Consolidated sourcing of sealing materials
-
Custom cutting and OEM fabrication support
-
Mixed-item container loading
-
Export-compliant packaging and documentation
This approach helps buyers reduce supplier count, simplify logistics, and control total landed cost.
Quality & Compliance
-
ISO 9001 certified manufacturing system
-
UKAS verified asbestos-free material
-
Suitable for international industrial standards
-
Consistent batch testing and documentation
Summary for Procurement Managers
By combining laser-cut compatibility, custom size flexibility, and one-stop export sourcing, this non-asbestos gasket sheet provides a practical, scalable sealing solution for OEMs, distributors, and industrial end users seeking long-term reliability and streamlined procurement.
