Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use

Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use
Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use
Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use
Basic Information
Place of Origin: CHINA
Brand Name: CLINGSEAL
Certification: ISO,SGS
Model Number: NXB150
Minimum Order Quantity: 500KGS
Price: 1.5-4 USD PER KG
Packaging Details: pallets or wooden case
Delivery Time: 10-20 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 200Tons per month
Get Best Price Contact Now
Detail Information
Color: Black Material: Non Asbestos Fiber
Application: Sealing Density: 1.5 G/cm3
Compressibility: 7-17% Recovery: 40%
Working Temperature: 150Deg Elongation At Break: ≥ 10%
Ph Range: 2-14 Temperature Range: Up To 500°C
Feature: Customized Temperature: 200-500 Celsius Degrees
Thickness: 0.5mm-6.0mm Width: 1m
Length: 1m Pressure: 2.0-5.0Mpa
Tensile Strength: ≥ 9 MPa Pressure Range: Up To 100 Bar
Certifications: ISO 9001, ISO 14001, OHSAS 18001 Product Type: Gasket Sheet
Flexural Strength: 15 MPa Sealing Performance: High
Fluid Resistance: Excellent Standard Size: 1000mm X 1000mm
Steam Resistance: Good Size: Standard Sizes Or Customized

Product Description

Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use 0

On this page, you can buy non-asbestos jointing gaskets with thicknesses from 0.5mm to 5mm. A smart move is to select the thinnest material that meets your specific application requirements. This not only cuts costs but also may enhance your equipment's overall performance.​
Basic Characteristics of Non-Asbestos Jointing Gasket Sheet​
Made by compressing aramid fiber and nitrile butadiene rubber (NBR), non-asbestos jointing gaskets boast excellent oil resistance. They’re also ideal for situations where they might encounter substances such as water, gasoline, or natural gas.​
These properties make non-asbestos jointing gaskets widely used in various fields. They’re commonly seen in air compressors, diesel engines, pipelines, and are suitable for a wide range of general industrial and marine environments.​
Product Details​
This gasket is composed of aramid fiber, non-asbestos mineral fiber, synthetic fiber, and synthetic oil-resistant rubber. Its manufacturing process involves hot-roller compression followed by vulcanization, ensuring high quality and long-term performance.



The following table summarizes the general properties:



Property Description
Oil Resistance Excellent ability to resist oil, maintaining integrity in oil - rich environments
Compatibility Can be used in contact with water, petrol, and natural gas
Product Advantages​
  • Strong Adaptability and Durability: The gasket adapts well to different working conditions and is highly durable. It provides excellent sealing performance to stop leaks, won’t delaminate during use, and has a high yield rate—resulting in less waste during production and installation.​
  • Cost-Effective Choice: It’s an economical option for sealing gaskets and exhaust manifold gasket materials, allowing you to get high-quality sealing at a reasonable price.​
  • Quality Assured: Certified by ISO9001 UKAS, the product is 100% asbestos-free, making it environmentally friendly and safe for users.​
  • Excellent Oil Resistance: Its good oil resistance prolongs its service life in oil-related applications.

Product Types

Based on different temperature tolerances (the numbers represent peak temperatures), the product comes in the following types:



Product Type Peak Temperature
CSNXB150 150°C
CSNXB250 250°C
CSNXB350 350°C
Product Applications​
The gasket is suitable for multiple uses, including:​
  • Engine: Ensures tight sealing in engines to prevent oil and gas leaks, keeping the engine running efficiently.​
  • Air Compressor: Helps maintain airtightness in air compressors, boosting their performance.​
  • Gearbox: Offers reliable sealing in gearboxes, protecting internal components from contaminants.​
  • Pipe and Flange Sealing: Used to seal pipelines and flanges, preventing fluid leaks in industrial and other systems.​
Product Sizes​
  • Thickness: Ranges from 0.5mm to 5.0mm, so you can choose the most suitable thickness for your needs.​
  • Standard Sizes: We provide several standard sizes, such as 1500×1500mm, 1500×2000mm, 1500×4500mm, 1270×1270mm, and 1270×3810mm.​
  • Custom Sizes: In addition to standard sizes, we also accept custom size orders. Just provide your specific size requirements, and we’ll manufacture the gasket to fit exactly.​
  •

Physical Property:

Items CSNXB150 CSNXB250 CSNXB350
Tensile Strength Mpa 7.0 8.0 10.0
Compressibility % 7-17
Recovery ≥% 40 45 50
Creep relaxation ≤% 40 35 30
Density g/cm3 1.8±0.1
Flexibility at room temperature Bend 180°C on the rod with diameter which is 12 times of nominal thickness of the sample, no crack.
Immersed into ASTM 3# at 150ºC for 5h Tensile Strength MPa≥ 5.0 6.0 7.0
Weight Increase ≤% 30
Immersed into ASTM B at21-30ºC for 5h Thickness Increase - 0-20
Flexibility - No crack
Working Temperature Max/Continuous ºC 200/150 300/250 350/300
Working Pressure Max/Continuous MPa 2.0/1.0 4.0/2.0 5.0/3.0

Product Shows
Product Technical Details
As a general rule, Non-asbestos jointing gasket sheet is:
• Good for use with water
• Good for use with petrol
• Have good resistance to oil



Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use 5

Custom Molded Non-Standard Gaskets – Flat Non-Asbestos Joint Sheet with Injection Rubber and Plastic Materials for Industrial Sealing Use 6
