Detail Information

Grade:	Industrial Grade	Type:	Flexible Sheet,Composite Sheet,Reinforced Sheet
Application:	Gaskets	C Content (%):	99.9%,99%
Thickness:	Customers' Demand,1.5MM-5.0MM	Material:	High Purity Graphtite,Graphite
Width:	≤1500 Mm	Color:	Black
Hardness:	80 Shore A	Compressibility (%):	10–20
Shape:	Can Be Customized	Sample:	Availble
Density:	1.0~1.5g/cm3	Thickness Deviation (mm):	0.05
Highlight:	sealing reinforced graphite sheet , sealing reinforced graphite gasket sheet , composite reinforced graphite sheet

Product Description

Reinforced Graphite Composite Gasket with Tinplate Product Description

Low Creep Reinforced Graphite Gasket Sheets for Industrial Sealing Solutions

Looking for high-performance, reliable industrial sealing materials? Discover our Low Creep Reinforced Graphite Gasket Sheets—engineered to deliver superior sealing under extreme conditions. Ideal for steam, exhaust, and high-pressure applications, these gaskets combine durability, adaptability, and cost-effectiveness for optimal performance.

Product Overview
Our reinforced graphite gasket sheets feature a sandwich design: two layers of pure flexible graphite (95-99% carbon content) bonded with a perforated metal insert (0.2-0.25mm carbon steel/tinplate, SS201, 304, or 316). This construction ensures low creep relaxation, excellent compression recovery, and resistance to corrosion, making them suitable for temperatures up to 800°C and pressures exceeding 100 bar.

Low Creep Reinforced Graphite Gasket Sheets for Industrial Sealing 0

Key Features

High-Temperature & Pressure Resistance: Withstand extreme environments in power plants, refineries, and automotive systems.
Superior Sealing Performance: Low creep properties prevent gasket failure under prolonged stress.
Chemical & Oil Resistant: Maintain integrity in aggressive fluids.
Customizable Solutions: Choose thickness (1.0-6.0mm) and sizes (500x500mm to 1000x1500mm), including multi-layered 3+2 configurations.
Cost-Effective: Balances performance with affordability for industrial sealing needs.

Applications
Perfect for critical sealing in:

Steam turbines, boilers, and exhaust manifolds
Petrochemical pipelines and flange connections
Automotive cylinder head gaskets
Marine engine systems

Why Choose Our Graphite Gaskets?

No Delamination: Advanced bonding technology ensures layers stay intact.
High Yield: Minimize waste with precise die-cutting capabilities.
Global Compliance: Meet ISO, ASME, and API standards.

Need a Custom Solution?
If standard sizes or materials don’t fit your requirements, contact our experts for bespoke designs. Use our Gasket Material Selector or download our free Rubber Guide to compare options.

Order Now
Browse thickness options (1.0-3mm standard) and request samples. For bulk orders or custom specs, get in touch—we’re here to support your industrial sealing needs.

Physical Property:

Item		Data
Tensile Strength (MPa,min.)		≥30
Compressibility (%,)		10-20
Recovery (%)		≥35
150ºC, At IRM 903# for 5hours	Thickness Increase(%)	≤10
	Weight Increase(%)	≤10
21ºC~30ºC, At B Fuel for 5hours	Thickness Increase(%)	≤10
	Weight Increase(%)	≤10
Thickness Deviation(mm)		0.05

Product Technical Details
As a general rule, graphite is:
• Good for use with steam
• Good ozone resistance
• Good with natural gas

Customer Service

We are happy to answer any questions that you might have about this product. Please contact us for more information.

Product Shows

About Us

Tag:

Place of Origin:	CHINA
Brand Name:	CLINGSEAL
Certification:	ISO,SGS
Model Number:	CS1080T

Minimum Order Quantity:	500KGS
Price:	USD 2.15-3.0 PER KG
Packaging Details:	pallets or wooden case
Delivery Time:	1-4 weeks
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	100Tons per month
