Detail Information

Grade:	Industrial Grade	Type:	Flexible Sheet,Composite Sheet,Reinforced Sheet
Application:	Gaskets	C Content (%):	99.9%,99%
Thickness:	Customers' Demand,1.5MM-5.0MM	Material:	High Purity Graphtite,Graphite
Density:	1.0~1.5g/cm3	Color:	Black
Hardness:	80 Shore A	Shape:	Can Be Customized
Sample:	Availble	Width:	≤1500 Mm
Thickness Deviation (mm):	0.05	Pressure Resistance:	High - Pressure Suitable
Highlight:	composite reinforced graphite sheet , composite reinforced graphite gasket sheet , 80 shore a reinforced graphite sheet

Product Description

Reinforced Graphite Composite Gasket with Tinplate Product Description

High-Strength Reinforced Graphite Gasket Materials for Heavy Machinery

Discover premium-grade graphite gasket materials engineered for extreme performance in heavy machinery applications. Our reinforced graphite gaskets combine advanced design with superior materials to deliver unmatched sealing reliability under high temperature and pressure conditions.

Product Overview
Our high-strength reinforced graphite gaskets feature a composite structure of pure flexible graphite sheets (95-99% carbon content) bonded with a precision perforated metal insert (0.2-0.25mm carbon steel, SS201, 304, or 316). This design ensures exceptional adaptability, durability, and resistance to thermal cycling, making them ideal for demanding environments like steam systems, exhaust manifolds, and industrial machinery.

High-Strength Reinforced Graphite Gasket Materials for Heavy Machinery 0

Key Features

Extreme Temperature & Pressure Resistance: Withstand up to 800°C and 100 bar, ensuring long-term performance in harsh conditions.
Oil & Chemical Resilience: Maintain integrity in hydrocarbon-rich environments.
No Delamination Technology: Proprietary bonding prevents layer separation, reducing downtime and replacement costs.
Customizable Thickness: Available in 1.0-6.0mm standard sizes, including 3+2 multi-layer configurations (Paper-Metal-Paper-Metal-Paper) for specialized needs.
Cost-Effective Sealing: Balances high performance with affordability, ideal for large-scale industrial projects.

Applications
Perfect for critical heavy machinery components:

Cylinder head gaskets
Exhaust system seals
Valve and flange connections
Steam turbine and boiler assemblies

Custom Solutions
Need a bespoke gasket? Our team specializes in tailoring graphite gasket materials to unique specifications. Contact us for custom sizes, materials, or performance requirements.

Why Choose Us?

ISO-certified manufacturing processes
Fast global shipping for bulk orders
Expert technical support for material selection

Physical Property:

Item		Data
Tensile Strength (MPa,min.)		≥30
Compressibility (%,)		10-20
Recovery (%)		≥35
150ºC, At IRM 903# for 5hours	Thickness Increase(%)	≤10
	Weight Increase(%)	≤10
21ºC~30ºC, At B Fuel for 5hours	Thickness Increase(%)	≤10
	Weight Increase(%)	≤10
Thickness Deviation(mm)		0.05

Product Technical Details
As a general rule, graphite is:
• Good for use with steam
• Good ozone resistance
• Good with natural gas

Customer Service

We are happy to answer any questions that you might have about this product. Please contact us for more information.

Product Shows

About Us

Tag:

Place of Origin:	CHINA
Brand Name:	CLINGSEAL
Certification:	ISO,SGS
Model Number:	CS1080T

Minimum Order Quantity:	500KGS
Price:	USD 2.15-3.0 PER KG
Packaging Details:	pallets or wooden case
Delivery Time:	1-4 weeks
Payment Terms:	T/T, Western Union, MoneyGram
Supply Ability:	100Tons per month
