High-Performance Graphite Gasket Sheets for Chemical Plants

Name: High-Performance Graphite Gasket Sheets for Chemical Plants
Brand: Anqing Cling-Seal Manufactory Co., Ltd.
SKU: CS1080T
Price: 2.15 USD
Availability: InStock

quality High-Performance Graphite Gasket Sheets for Chemical Plants factory

Product Specification

Place of Origin: CHINA

Brand Name: CLINGSEAL

Certification: ISO,SGS

Model Number: CS1080T

Minimum Order Quantity: 500KGS

Price: USD 2.15-3.0 PER KG

Payment Terms: T/T, Western Union, MoneyGram

Supply Ability: 100Tons per month

Product Details

Highlight:

composite reinforced graphite sheet

composite reinforced graphite gasket sheet

80 shore a reinforced graphite sheet

Grade: Industrial Grade

Type: Flexible Sheet,Composite Sheet,Reinforced Sheet

Application: Gaskets

Thickness: Customers' Demand,1.5MM-5.0MM

Material: High Purity Graphtite,Graphite

Color: Black

Hardness: 80 Shore A

Product Name: Reinforced Graphite Composite Gasket Sheet

Shape: Can Be Customized

Sample: Availble

Width: ≤1500 Mm

Carbon Content (%): 95%,97%,98%,99.9%,99%

Density: 1.0~1.5g/cm3

Product Description

Reinforced Graphite Composite Gasket with Tinplate Product Description

High-Performance Graphite Gasket Sheets for Chemical Plants
Discover premium-grade Graphite Gasket Sheets engineered for extreme chemical plant environments. Engineered with precision, these sheets deliver unmatched sealing performance under high temperatures and pressures, making them ideal for critical industrial applications.

Key Features & Benefits

Multi-Layer Composite Design: Constructed with two layers of pure flexible graphite (95-99% carbon content) and a corrosion-resistant perforated metal insert (0.2-0.25mm carbon steel, SS201, 304, or 316), ensuring superior strength and leak-proof reliability.
Exceptional Temperature & Pressure Resistance: Withstands continuous exposure to temperatures up to [insert max temp]°C and pressures exceeding [insert max pressure] PSI, making them perfect for steam cycles, exhaust systems, and chemical processing.
Oil & Chemical Resilience: Maintains integrity in aggressive fluids, preventing degradation and ensuring long-term durability.
Cost-Effective Solution: Balances high performance with affordability, reducing downtime and replacement costs.
Customizable Options: Available in thicknesses from 1.0mm to 6.0mm (including 3+2 multi-layer configurations) and standard sizes like 500x500mm or 1000x1500mm. Tailor to your exact specifications!

High-Performance Graphite Gasket Sheets for Chemical Plants 0

Why Choose Our Graphite Gaskets?

Superior Sealing: No delamination or leakage, even in dynamic operating conditions.
Versatile Applications: Ideal for cylinder head gaskets, flange seals, and equipment in chemical, petrochemical, and power generation plants.
Global Compliance: Meet ISO, ASME, and API standards for safety and quality.

Technical Specifications

Material: Flexible graphite + perforated metal core
Thickness: 1.0-6.0mm (customizable)
Standard Sizes: 500x500mm, 500x1000mm, 1000x1000mm, 1000x1500mm
Carbon Purity: 95%, 97%, 98%, or 99%
Metal Options: Carbon steel (tinplate), SS201, SS304, SS316

Need Custom Solutions?

If you require bespoke thicknesses, sizes, or material combinations, contact our experts for tailored advice. Use our Gasket Material Selector tool to find the perfect fit, or download our Rubber Guide for alternative options.

Shop Now for high-performance Graphite Gasket Sheets designed to optimize safety and efficiency in chemical plant operations. Request a quote or chat with us for bulk orders and exclusive pricing!

Physical Property:

Item		Data
Tensile Strength (MPa,min.)		≥30
Compressibility (%,)		10-20
Recovery (%)		≥35
150ºC, At IRM 903# for 5hours	Thickness Increase(%)	≤10
	Weight Increase(%)	≤10
21ºC~30ºC, At B Fuel for 5hours	Thickness Increase(%)	≤10
	Weight Increase(%)	≤10
Thickness Deviation(mm)		0.05

Product Technical Details
As a general rule, graphite is:
• Good for use with steam
• Good ozone resistance
• Good with natural gas
